Product Description

Description:

• This module is compatible with all laptops that have a mini PCI-E internal slot.except IBM and HP laptop.
• The Atheros AR5008 chipsets are Atheros' highest performance wireless LAN solutions to date.
AR5008 products are compliant to the draft 802.11n specification, to deliver the ultimate wireless triple play experience for video, voice and data transmission throughout the home or office.
•Video:With real world throughput levels up to 300 Mbps PHY rate, new wireless routers and gateways featuring Atheros XSPAN technology will readily accommodate multiple high-definition (HD) streams on a single home network.
•Voice:Single-antenna wireless voice handsets and legacy devices networked to Atheros-based access points achieve range and robustness from Atheros?triple transmitter architecture.
•Data:The array of data applications ranging from simple network computing to transmission of large data, music or image files is enhanced through the high bandwidth provided by XSPAN products.

•AR5008E-3NG

Specifications:

• Frequency Band: 2.300 to 2.500 GHz
•Network Standard: 802.11b, 802.11g, draft 802.11n
•Modulation Technology: OFDM with BPSK, QPSK, 16 QAM, 64 QAM; DBPSK, DQPSK, CCK
•FEC Coding Rate: 1/2, 2/3, 3/4, 5/6
•Hardware Encryption: AES, TKIP, WEP
•Quality of Service: 802.11e
•Communications Interface: PCI, CardBus
•Peripheral Interface: GPIOs, LEDs
•Memory Interfaces: EEPROM
•Supported Data Rates:
IEEE 802.11b (1 to 11 Mbps)
IEEE 802.11g (6 to 54 Mbps)
XSPAN (6.5 to 300 Mbps)

Package includes:

•1 x AR5008 AR5BXB72 Wireless Mini PCI-E Wifi Card

Feature

This module is compatible with ALL laptops that have a mini PCI-E internal slot. except IBM, HP machines
AR5008 products are compliant to the draft 802.11n specification, to deliver the ultimate wireless triple play experience for video, voice and data transmission throughout the
Video:With real world throughput levels up to 300 Mbps PHY rate, new wireless routers and gateways featuring Atheros XSPAN technology will readily accommodate multiple high-definition (HD) streams on a single home network.
Voice:Single-antenna wireless voice handsets and legacy devices networked to Atheros-based access points achieve range and robustness from Atheros?triple transmitter architecture.
Data:The array of data applications ranging from simple network computing to transmission of large data, music or image files is enhanced through the high bandwidth provided by XSPAN products.
Brand : Atheros
Item model num : AR5BXB72
MPN(PartNumber) : AR5BXB72
EAN : 0520624360286
Product Dimensions(LxWxH) : 20x13x1cm ; 2404 g
Package Dimensions(LxWxH) : 20x13x1cm ; 2404 g
